MVI69-ADM Prosoft Programmable Application Development Module for CompactLogix

Brand Name : Prosoft

Model Number : MVI69-ADM

Certification : CO.CQ

Place of Origin : USA

MOQ : 1

Price : inquiry

Payment Terms : T/T

Supply Ability : 10 pieces a day

Delivery Time : today

Packaging Details : new and original with factory sealed

Manufacture Year : 2016

Control System : MVI69-ADM

Application : Nuclear Power Plant

lead time : in stock

description : Prosoft

Weight : 4lbs

Contact Now

MVI69-ADM Prosoft Programmable Application Development Module for CompactLogix

MVI69-ADM

The MVI69 Application Development Module is a CompactLogix backplane compatible module that allows user-developed 'C' applications to operate on the CompactLogix platform. A great way to speed up custom ASCII data communications or to protect a proprietary algorithm, the ADM is a powerful tool for the CompactLogix platform.

Features and Benefits

Powerful platform for developing and running 'C' applications on Rockwell Automation's CompactLogix processors. The MVI69 Application Development Module is a single slot, backplane compatible solution for the Rockwell Automation CompactLogix platform. This module is a powerful and programmable solution supporting two fully isolated serial ports allowing the many serial field devices to be integrated into the CompactLogix platform.

The MVI69-ADM module has three serial ports, two of which are isolated for field interfaces:

  • CFG: Debug/configuration RS-232
  • PRT1: Application RS-232, RS-422 or RS-485
  • PRT2: Application RS-232, RS-422 or RS-485

PRT1 and PRT2 are jumper configured for direct or multi-drop field communication. The application program can be written to control the two application ports independently, allowing maximum flexibility in the design.

Applications

The MVI69-ADM module is the ideal solution for many applications where serial connectivity must be added to a CompactLogix platform. Applications using the MVI69-ADM module include:

  • Bar code scanner interface
  • Legacy ASCII protocol connections
  • Terminal port emulation
  • Printer driver (alarm/status printer)
  • Customized protocol implementations

Specifications

  • Single Slot - 1769 backplane compatible
  • The module is recognized as an Input/Output module and has access to processor memory for data transfer between processor and module
  • Ladder Logic is used for data transfer between module and processor.
  • Supports all CompactLogix processors: L20/L23/L30/L31/L32/L35, L43 and L45 (L43 and L45 supported with RSLogix 5000 v16.03 or later)
  • Supports MicroLogix 1500 Controller with LRP firmware version 6.0 or newer.
